Fleming Agri 4ft Hydraulic Compact Transport Boxes
Fleming Agri 4ft Hydraulic Compact Transport Boxes
The Fleming Agri 4ft hydraulic compact transport box is from Fleming Agri’s compact hydraulic transport box range which offers transport boxes 4ft (1.25m) (HYD4) and 5ft (1.5m) (HYD5C ). It is suitable for all compact and sub compact tractors. The computer aided design of the box allows the unit to be used to scoop up material and contain it in transport without the need for a back door.
The internal reinforcing shoes tie the strength of the floor to the cross beams on the back of the box creating a solid back plate to absorb the force of high horse power tractors. The reinforcing shoes have smooth rounded edges for easy unloading and cleaning.
It offers a heavy duty double acting ram. The heel of the box is fitted with a scraping blade, supported by the floor skids further adding reinforcing strength to the back of the box and giving the capability of grading and levelling stones, sand, soil ,etc.
It boasts a solid construction of reinforced 3mm steel plate. HYD4C requires double acting spool valve and has a range of 3PL settings to suit most tractors, has a double jaw lift arm pin support and is suitable for max. horse power of 50. Cat 1 pins supplied.
Specification for Fleming Agri 4ft Hydraulic Compact Transport Boxes
Leave a Review
Ask a Question
Videos
-
Description
The Fleming Agri 4ft hydraulic compact transport box is from Fleming Agri’s compact hydraulic transport box range which offers transport boxes 4ft (1.25m) (HYD4) and 5ft (1.5m) (HYD5C ). It is suitable for all compact and sub compact tractors. The computer aided design of the box allows the unit to be used to scoop up material and contain it in transport without the need for a back door.
The internal reinforcing shoes tie the strength of the floor to the cross beams on the back of the box creating a solid back plate to absorb the force of high horse power tractors. The reinforcing shoes have smooth rounded edges for easy unloading and cleaning.
It offers a heavy duty double acting ram. The heel of the box is fitted with a scraping blade, supported by the floor skids further adding reinforcing strength to the back of the box and giving the capability of grading and levelling stones, sand, soil ,etc.
It boasts a solid construction of reinforced 3mm steel plate. HYD4C requires double acting spool valve and has a range of 3PL settings to suit most tractors, has a double jaw lift arm pin support and is suitable for max. horse power of 50. Cat 1 pins supplied.
-
Specifications
4ft 129kg 1260mm 510mm 640mm 0.34m3 50 3mm Cat 1 No Yes -
